Golf simulator room dimensions: measure the right segments
Golf simulator room dimensions depend on the exact equipment and the people using it. The chart below separates sensor-to-ball distances, ball flight, and overhead mounting measurements from room recommendations. Add screen setback and assess personal swing clearance separately; a sum of equipment distances does not certify a room as safe.
Start with the model-specific golf simulator room dimensions chart
The documented distances below describe different parts of a simulator setup. A behind-ball sensor needs its position recorded relative to the ball. An overhead unit may use a mounting measurement. Read the endpoints and the requirement label before comparing a row with the dimensions on your room sketch.
Scroll sideways to read all columns. Keyboard: focus the table area and use the arrow keys.
| Monitor | Dimension | Measurement endpoints | Published value | Meaning |
|---|---|---|---|---|
| Garmin R10 | Sensor to ball | sensor position to tee | 6 ft (1828.8 mm) to 8 ft (2438.4 mm) | Setup range |
| Garmin R10 | Ball flight | tee to net impact plane | 8 ft (2438.4 mm) | Minimum |
| Flightscope Mevo+ | Sensor to ball | sensor position to tee | 7 ft (2133.6 mm) to 9 ft (2743.2 mm) | Setup range |
| Flightscope Mevo+ | Ball flight | tee to net impact plane | 8 ft (2438.4 mm) | Minimum |
| Rapsodo MLM2Pro | Sensor to ball | sensor position to ball | 6.5 ft (1981.2 mm) to 8.5 ft (2590.8 mm) | Setup range |
| Rapsodo MLM2Pro | Ball flight | ball to net impact plane | 8 ft (2438.4 mm) | Minimum |
| Uneekor EyeXO | Mounting height | top of hitting area to bottom of mounting bracket | 9 ft (2743.2 mm) to 10 ft (3048 mm) | Mounting range |
| Uneekor EyeXO2 | Room width | room boundary to opposite room boundary | 13 ft (3962.4 mm) | Recommendation |
| Uneekor EyeXO2 | Room depth | room boundary to opposite room boundary | 16 ft (4876.8 mm) | Recommendation |
| Uneekor EyeXO2 | Room height | room boundary to opposite room boundary | 10 ft (3048 mm) | Recommendation |
| SKYTRAK ST MAX | Room depth | room boundary to opposite room boundary | Printed as 10 ft (3048 mm) and 3.35 m (3350 mm); the figures disagree and neither is chosen | Recommendation |
| SKYTRAK ST MAX | Room width | room boundary to opposite room boundary | Printed as 10 ft (3048 mm) and 3.35 m (3350 mm); the figures disagree and neither is chosen | Recommendation |
Source: GarminRead September 21, 2026
Preparing for a Shot · Publication date not stated for this section
between 6 ft. and 8 ft.
Primary document read by an agent; extracted text retained. No physical testing or human review asserted.
Source: GarminRead September 21, 2026
Preparing for a Shot · Publication date not stated for this section
at least 8 ft. (2.4 m) away from the net
Primary document read by an agent; extracted text retained. No physical testing or human review asserted.
Source: FlightScopeRead September 21, 2026
Can Mevo+ be used indoors and outdoors? How much space is needed? · Publication date not stated for this section
7-9 feet sensor to tee distance
Primary document read by an agent; extracted text retained. No physical testing or human review asserted.
Source: FlightScopeRead September 21, 2026
Can Mevo+ be used indoors and outdoors? How much space is needed? · Publication date not stated for this section
8 feet of ball flight minimim
Primary document read by an agent; extracted text retained. No physical testing or human review asserted.
Source: RapsodoRead September 21, 2026
What are the ideal space requirements to set up MLM2PRO™ indoors? · Publication date not stated for this section
6.5-8.5 feet behind the ball
Primary document read by an agent; extracted text retained. No physical testing or human review asserted.
Source: RapsodoRead September 21, 2026
What are the ideal space requirements to set up MLM2PRO™ indoors? · Publication date not stated for this section
8 feet is needed from ball to the net
Primary document read by an agent; extracted text retained. No physical testing or human review asserted.
Source: UneekorRead September 21, 2026
How much space is needed for setup? · Publication date not stated for this section
mounted between 9 ft - 10 ft off the ground
Primary document read by an agent; extracted text retained. No physical testing or human review asserted.
Source: UneekorRead September 21, 2026
Specifications · Publication date not stated for this section
13 ft wide × 16 ft deep × 10 ft high
Primary document read by an agent; extracted text retained. No physical testing or human review asserted.
Source: SKYTRAKRead September 20, 2026
Minimum Unobstructed Area Dimensions · Publication date not stated for this section
Length: 10 feet (3.35m)
The feet figure printed in this line of the ST MAX user guide. The metre figure printed beside it (3.35 m) does not agree; both are kept on the record and neither is chosen.
Source: SKYTRAKRead September 20, 2026
Minimum Unobstructed Area Dimensions · Publication date not stated for this section
Width: 10 feet (3.35m)
The feet figure printed in this line of the ST MAX user guide. The metre figure printed beside it (3.35 m) does not agree; both are kept on the record and neither is chosen.
These rows do not form a universal room-size recommendation. They describe the cited equipment guidance. Where a model has no verified measurement in this chart, obtain its installation instructions before drawing a conclusion. A missing row does not mean that the equipment needs no clearance.
Draw the room as separate segments
Mark the intended hitting position on a plan. Record the sensor-to-ball distance, the ball-to-net or screen distance, and the screen setback separately. Keep any other installation clearances on the same drawing. Adding two documented segments does not account for a third segment that you have not measured.
Make a separate overhead sketch. Include the finished hitting surface and the lowest obstruction near the swing area. A beam, light, or garage-door track can make the available clearance different from a measurement taken elsewhere. Read the ceiling-height guide before comparing a room-height label with a mounting range.
These distances matter most inside a pairing you are actually considering. The Garmin R10 pairing on GSPro and the Mevo+ pairing on GSPro both rest on a behind-the-ball placement, and the matrix of documented listings names the party that published each one.
Keep recommendations and requirements distinct
A manufacturer can describe a recommended room size without calling every dimension a required minimum. Preserve that distinction in your notes. Do not turn a recommendation into a universal threshold, and do not treat meeting an equipment dimension as approval for a golfer to swing.
The room also needs an assessment for the people using it. Handedness, hitting position, club choice, and overhead equipment all belong in that discussion. We have not inspected your room, tested its containment, or measured anyone’s swing. Avoid a full-speed test swing in a confined space when clearance remains uncertain.
Keep the computer and software checks alongside the room
The host computer and display need a place on the plan, but software support does not establish physical fit. Read the GSPro software guide or E6 CONNECT guide for the separate host and license questions. Leave cable routing and equipment positions visible for the installer.
Use the room-planning hub to keep the checks together. Our source process explains why we attach the model, measurement endpoints, and reading date to each answer. Keep those details with your quote so that a change of equipment sends you back to the correct source.
Common questions
Can I add the sensor and ball-flight distances to get a room length?
That gives only the measured segments in the equipment instructions. You still need screen or net setback and any other space required by the installation. It does not establish swing clearance or ball containment.
Is a recommended room size a minimum?
Keep the publisher’s label. A recommendation and a required minimum are different statements. Neither establishes that every golfer can swing safely in that room.
Does a thick mat affect mounting height?
It can change the measurement when the instructions use the top of the hitting area as an endpoint. Measure from the specified surface instead of substituting the bare floor.
GolfCompat provides planning information. Confirm the instructions for your exact equipment and have your room, swing clearance, and installation assessed before use. A listed equipment requirement does not certify personal safety.
